Applications advantages of AK06 for HPS

A component of any HPS is the motor. Usually the VSD is located close to the motor, and there is no need for a long line. It is common to configure a VSD without using an output filter, which minimizes the voltage drop at the VSD output and allows the motor input terminals to have the rated voltage or voltage within the motor tolerance. However, not using a filter, specifically a sine filter (SF), leads to non-sinusoidal voltage, increased heating of the motor windings, and reduced motor life. Old and overhauled motors are susceptible to these influences.

Triol Corporation offers VSD with a built-in sine filter for operation as the HPS part under the condition of motor operation in the soft mode when the motor is not fully loaded. Application of the sine filter provides THDu ≤ 5% and thus reduces heating of the motor windings, insulation aging, and under conditions when the motor is not loaded, the mechanical wear of friction pairs is reduced. In sum, these advantages increase motor and equipment durability and reliability.

Figure 2 - Voltage shape after the sine filter

Since the volume of the pumped gas-liquid mixture can be up to 70,000 bpd, stopping the equipment for repair may lead to significant financial losses. HPS systems are equipped with sensors and warning systems to protect the equipment.

Variable speed drives Triol allows the use of a wide range of inputs/outputs to handle external signals, which is achieved by installing expansion units that have up to 20 digital inputs (Din) and up to 10 digital outputs (Dout), or up to 22 analog inputs (Ain) and 8 analog outputs (8 Aout), depending on the expansion unit configuration.

Figure 3 - VSD Triol expansion units configurations

It is also possible to quickly replace the unit when, for example, you switch to another type of sensor.

Figure 4 - Expansion module connection compartment

The software allows complete external sensor configuration, from setting a unique sensor name for the maintenance staff’s convenience to setting the system operating limits based on the data received from the sensors.

Figure 5 - I/O settings in the UMKA07 menu

VSD allows automatic adjustments of the optimum voltage. The benchmark for the optimal voltage is the minimum operating motor current. The optimum voltage automatic selection allows one to select the motor voltage depending on the operating conditions of the motor. Automatic selection is performed in cyclic mode within a preset interval after setting the operating frequency and/or after changing the motor rotation speed. This mode saves up to 10% of the power consumed by the entire application.

Triol Corporation has solutions with a built-in passive filter in the CP and LH lines. These lines allow the input THDi deviation to be kept to less than 5% at 25% to 100% load. The difference between the lines is the degree of enclosure protection - NEMA4/4X for the CP line and NEMA3R for the LH line.

Figure 6 - AK06 SR line (left) and LH line (right) overview

An integral part of the operation of modern systems is the remote technological process control, which allows one to reduce operating costs of the equipment. Triol Corporation has excellent experience connecting its frequency drives to the customer’s SCADA system.

Figure 7 - The automated technological process control panel

VSDs are provided with the possibility of connection to SCADA system using communication interfaces RS232 and RS485. The software supports data exchange via Modbus communication protocol in the user’s SCADA system. What is important is that it is also possible to add data to the parameters of the frequency drive but also to connect external sensors and systems to the SCADA system.

Figure 8 - ACS on the Triol ITA example

The UMKA07 HMI controller allows one to configure the control in the shortest time due to the multi-level display of the submenus.

Figure 9 - UMKA07 Menu Example

The module design allows one to minimize the repair time of the VSD. Every module can be replaced in less than 30 minutes.

Figure 10 - Power compartment by the example of AK06 line RD

Based on our experience on oil platforms, Triol has optimized the VSD design of compartments and units to achieve the smallest possible VSD footprint, allowing you to reduce your logistics losses and the space required to install your equipment.

Triol - Solutions from oil production to the end-user delivery
